Pes Capsule Filter for Pharmaceutical and Food Industry

Pes Capsule Filter for Pharmaceutical and Food Industry

  • Pes Capsule Filter for Pharmaceutical and Food Industry
  • Pes Capsule Filter for Pharmaceutical and Food Industry
  • Pes Capsule Filter for Pharmaceutical and Food Industry
  • Pes Capsule Filter for Pharmaceutical and Food Industry
  • Pes Capsule Filter for Pharmaceutical and Food Industry
Model No.: Pes Capsule Filter
Min. Order: 25 Piece/Pieces
Payment Type: L/C,T/T,D/P,Paypal,Western Union
Transportation: Ocean,Land,Air
Productivity: 100000PCS/Year
Packaging: Carton Packing
Delivery Time: 10-15 Days
Place of Origin: china
Brand: QingFeng,OEM
Supply Ability: 100000PCS/Year
Certificate: SGS and ISO9001

Product Description


Product description

                                                                     Capsule Filters

Kinds of membrane materials can be chosen by the customer's requirements.  Made up of polypropylene cage and pleated membrane filter insider by thermal bonding, good integrality, free of surfactants and adhesives.

Main Characteristics:

Incorporate the full range of filter medias (PP,PS,PF,PV),with the housing out, can be used directly; Ideal for small batch prefiltration and final filtration of liquid or gas in laboratory. Different kinds of connections are for options. Easy to install and convenient to use

PES Capsule Filter:

Typical Applications Of PES Capsule Filter :

PES Capsule filter is with PES filter membrane , high flow rate, low adsorption of protein; Suitable for large sample volume and something difficult to filter. Widely used in the filtration of pharmaceutical, food and beverage and the filtration of small injection, tissue cultural media and liquid filtration.

Micron Rating(µm):

PES:  0.10   0.20    0.45   0.65

Materials of Construction:

Filter Media: PES Membrane

Inner Core: Polypropylene

Outer Core: Polypropylene


Cartridge Dimensions:

Length: 2.5" 5"

Effective Filtration Area: 2.5" ≥0.14m3    5" ≥0.28m3

Connections: 1/8" NPT; 1/4" NPT; 1/4" CNPT; 1/2" NPT; 9/16" hose barb; 1.5" sanitary flange


Operation Conditions:

Normal Operating Temperature: ≤55ºC

Max. Operating Temperature: 85ºC(△P≤0.10Mpa)

Max. Differential Pressure:  Normal Flow direction:4.2 bar at 25ºC

Reverse Flow direction: 2.1 bar at 25ºC


Cartridge Safety:

Endotoxin: <0.50 EU/ml

Extractable: 0.03g/10"


Pes Capsule Filter for Pharmaceutical and Food Industry

Pes Capsule Filter for Pharmaceutical and Food Industry
Pes Capsule Filter for Pharmaceutical and Food Industry
Pes Capsule Filter for Pharmaceutical and Food Industry
Pes Capsule Filter for Pharmaceutical and Food Industry
Pes Capsule Filter for Pharmaceutical and Food Industry
ABOUT US:

    QingFeng Filter Equipment Co., Ltd ,located in new industrial park, QingYuan area, Ji'an  Jiangxi Province, is a manufacturer in inustrial filtration and separation region , producing and marketing microfiltration products for pharmaceutical, food and beverage, chemical and electronic industries and other related liquid and gas filtration industries, such as filter membrane, filter cartridges, filter housing.

    Our factory has a full set of filter technology and filter production equipment (include quality monitoring equipment) which is imported from Japan. At the meantime, Our factory adhering to the technology advantage of CN-CA reinforced membrane( the important new product of 85 national torch plan) And Nylon reinforced membrane(the first Nylon creator). And our factory also the domestic leading technical level in producing reinforced PVDF membrane.  The products and services we offer will provide world class quality.
